The Morbark 1100 Tub Grinder, a versatile mid-sized grinder that offers an excellent balance of price and performance for wood waste processing and reduction. This grinder boasts a range of advanced features typically found only in larger models, making it a standout choice.
Benefit from the Morbark Integrated Control System (MICS), allowing precise adjustment of feed rates for various materials while maximizing fuel efficiency. The grinder also features a laser-cut, factory-balanced hammermill for optimal performance. Its dual hydraulic augers ensure consistent material flow, preventing plugging even during surges.
For added protection, the full breakaway torque limiter safeguards the engine and clutch from potential damage, ensuring long-term reliability. Discover the Morbark 1100 Tub Grinder for efficient wood waste management with enhanced performance features.
Specifications & Details
| GENERAL | US | METRIC |
| Length (transport) | 37' 2" | 11.33 m |
| Length (operating) | 56' 3" | 17.14 m |
| Height (transport) | 12' 9" | 3.88 m |
| Width | 9' 9" | 3 m |
| Gross Weight (NCL) | 48,630 lb | 22,058 kg |
| Gross Weight (WCL) | 59,920 lb | 27,180 kg |
| Axle Weight (NCL) | 34,830 lb | 15,800 kg |
| Axle Weight (WCL) | 40,540 lb | 18,390 kg |
| Tongue Weight (NCL) | 13,770 lb | 6,245 kg |
| Tongue Weight (WCL) | 19,380 lb | 8,790 kg |
| Engine | CAT | |
| Horsepower | 800 HP | 596 kW |
| Fuel Capacity (tank) | 300 gallons | 605 litres |
| Hydraulic Oil | 120 gallons | 454 litres |
| Screen Area | 2,174 sq in | 14,026 sq cm |
| Tires | (8) 255/70R/22.5 | |
| Towing Arrangement | Fifth wheel | |
| Brakes | Air |
What applications are Morbark tub grinders used in?
Morbark tub grinders are designed for the most challenging recycling applications. They excel at processing yard waste, pallets and other mixed woody feedstocks into saleable products. They can be used for processing whole trees, stumps, brush, construction and demolition debris, wood waste, and green waste.
What features are included on Morbark tub grinders?
Morbark tub grinders are equipped with hydraulic augers that allow the operator to quickly remove product beneath the mill, a full breakaway torque limiter system to protect the engine and clutch, a laser-cut, factory-balanced mill, and more.
What is the difference between tub grinders and horizontal grinders?
Both Morbark horizontal and tub grinders excel at processing wood waste into saleable products. Choosing between a horizontal grinder and a tub grinder depends on your specific needs, including the types of materials you need to process, desired output size and consistency, mobility requirements, space availability, and budget considerations. Horizontal grinders allow for continuous feeding of long and straight material, while tub grinders are ideal at processing bulky and irregularly shaped materials like whole trees, stumps, brush, and demolition debris.
What is the benefit of the externally adjustable break-away torque limiter?
For over a decade, Morbark's exclusive, Break-away Torque Limiter, has proven to be the industry's best solution for protecting the driveline of a horizontal or tub grinder from catastrophic failure. It reacts in milliseconds to a direct hit. No other system has this response time, which ultimately will save you downtime and money. The system is a standard feature on most current models of Morbark Wood Hog Horizontal Grinders and Tub Grinders.
What safety features are included in Morbark tub grinders?
Safety features may include emergency stop buttons, safety guards and shields, remote control operation, automatic shutdown systems, and hydraulic tilt tub for easy maintenance and inspection. These features help protect operators and ensure safe operation.
How can I purchase a Morbark tub grinder or replacement parts?
Morbark tub grinders and genuine OEM replacement parts can be purchased through authorized dealers and distributors. You can find a dealer near you by using our dealer locator tool.
